On Loom Take Up Motion Assembly
On Loom Take Up Motion Assembly
The On Loom Take-Up Motion Assembly is a precision-engineered system designed for smooth, accurate, and uniform fabric winding directly on the loom. Unlike standalone batching units, this assembly is installed inside the loom frame and functions as an integral part of the loom’s take-up mechanism.
The system operates in complete synchronization with the loom’s mechanical drive and electrical control system, ensuring precise fabric winding, consistent fabric tension, and reliable performance throughout the weaving process. Its robust construction and precision-engineered components help produce uniform, crease-free fabric rolls while maintaining excellent fabric quality and maximizing loom productivity.
The assembly is equipped with heavy-duty SG Iron Side Brackets, a Mechanical Tension Control Unit, and high-quality transmission components for smooth and reliable operation. It supports both single-width and dual-width weaving applications, making it suitable for a wide range of textile manufacturing requirements.
Designed for durability, easy installation, and low maintenance, the On Loom Take-Up Motion Assembly is an ideal solution for modern weaving plants seeking higher productivity, superior winding quality, and long service life.
The On Loom Take-Up Motion Assembly is a precision-engineered system designed for smooth, accurate, and uniform fabric winding directly on the loom. Unlike standalone batching units, this assembly is installed inside the loom frame and functions as an integral part of the loom’s take-up mechanism.
The system operates in complete synchronization with the loom’s mechanical drive and electrical control system, ensuring precise fabric winding, consistent fabric tension, and reliable performance throughout the weaving process. Its robust construction and precision-engineered components help produce uniform, crease-free fabric rolls while maintaining excellent fabric quality and maximizing loom productivity.
The assembly is equipped with heavy-duty SG Iron Side Brackets, a Mechanical Tension Control Unit, and high-quality transmission components for smooth and reliable operation. It supports both single-width and dual-width weaving applications, making it suitable for a wide range of textile manufacturing requirements.
Designed for durability, easy installation, and low maintenance, the On Loom Take-Up Motion Assembly is an ideal solution for modern weaving plants seeking higher productivity, superior winding quality, and long service life
Key Features
Key Features
Technical Specifications
Technical Specifications
| Particular | Specification |
|---|---|
| Product Name | On Loom Take-Up Motion Assembly |
| Installation | Inside the Loom Frame |
| Working System | Synchronized with Loom Mechanical Drive & Electrical Control System |
| Suitable Looms | Air Jet Looms & Other Compatible Textile Weaving Machines |
| Suitable Fabrics | Terry Towel, Technical Textiles, Denim, Cotton, Jute, Nonwoven & Other Woven Fabrics |
| Side Brackets | Heavy-Duty SG Iron Construction |
| Tension System | Precision Mechanical Tension Control Unit |
| Fabric Winding | Smooth, Uniform & Crease-Free |
| Roll Formation | Accurate & Consistent |
| Configuration | Single Width / Dual Width |
| Maintenance | Low Maintenance |
| Customization | Available for Specific Loom Models & Customer Requirements |
